Product description
Maintenance-free cheap and simple GPX V3 charger with balancer powered by 230V mains power. Compatible with lithium-polymer, lithium-ion and lithium-iron batteries 2S and 3S (7.4V and 11.1V). The charging process takes place via the balancer connector.
Designation of diode indicators:
Green light: power on
Red light: Charging
Blinking red light: error
Green light: the end of charging or the pause in charging
The charger has the option of switching to LiPo or LiFe charging mode.
Warning! Observe the order in which the charger starts: first connect the charger to the power supply, wait for it to start properly (the LED indicators will change from red to green) and only then connect the battery. When disabling, keep the reverse order.
Technical data
- Type of cells to be charged: Li-Po / Li-Fe
- Number of Li-Po / Li-Fe cells to be charged / voltage range: 2-3 / 7.4-11.1V
- LiPo / LiFe charging switch
- Charging current: 800mA 1
- 12WPower: max.
- Power supply: AC 110-240V
- Dimensions: 100 x 60 x 35mm
- Weight: 180g
Charging sockets: balancera service plug 2 and 3 targets, standard Gens Ace, Haiyin, E_Sky, Redox, Align, Turnigy
The set includes
- V3 charger with balancer
- Power cable
