LOGO 550 SX Kit

LOGO 550 SX Kit
  • Κωδικός/Model: MKD-02110
  • Βάρος Μεταφοράς: 8Kgr
  • Διαθεσιμότητα stock level
  • Κατασκευάζεται από: Mikado

499.00€Καλέστε για Πληροφορίες


The LOGO 550 SX is the first member of the next evolutionary step of our popular and proven LOGO 500/550/600 helicopter series.
Underneath the freshly designed canopy you find an improved version of our tried and tested chassis, which now offers a battery quick release system and considerably more headroom for flight packs below the counter bearing. The chassis will of course be available as upgrade kits for all existing 500/550/600 size LOGO helicopters.

- 550 mm main blades
- 6 S Lipo mit 4500-5000 mAh, a luminum rotor head yoke with 8mm spindle shaft
- light und durable chassis fiberglass reinforced frame with battery quick release system

- direct servo link to the swashplate
- Hollow main shaft with 10mm diameter
- Herringbone main gear with 153 teeth (module 0.7)
- Motor counterbearing with additional main shaft support
- colored fin set in neon red, matched with the canopy
- Extra-strong 22 mm diameter tail boom
- Detailed airbrush canopy in neon red


Specifications Helicopter
Rotor diameter 1245 mm
Rotor blades 550mm
RTF weight 2950 g
recommended batterie 6S 5000 mAh LiPo
Main gear ratio 9,56 - 12,75
Main Gear size 153 teeth Modul 07
batterie slot 62 x 54 x 300 mm (HxWxL)
Length 1070 mm
Hight 360 mm
Width 210 mm
Kit Kit with VBar Rotor Head
Accessories Motor counterbearing with mainshaft support
Manual detailed printed manual
Motors ---
Motor pinion ---
ESC ---
VBar electronic ---
Servos ---
Blades Rotortech 560mm
Tail Blades CFK 92mm
Canopy Airbrushed Canopy
