Spirit Systems Spirit 2

Spirit 2 - Evolution of Spirit. Universal flybarless and stabilisation unit for all models.

Hardware

• Very rigid, CNC milled, anodized and sandblasted enclosure
• Color: Red and Black, matt
• Material:  High quality AL6061-T6
• Dimension: 36.8x27.15x13.9mm, weight: 19g
• Power supply: 3 - 15V @ 25mA
• Operating temperature: -10°C to 60°C
• Latest generation, Ultra Fast
  32bit ARM processor: 210 DMIPS
• MEMS sensor with 12-Axis Sensor Fusion
  (rotation to 2000°/s !)
• Gold plated PCB with Pb-Free soldering
• Laser Engraved labels for perfect visibility.
• Integrated S-BUS Inverter
• 2x native Spektrum connectors
• 3x connector for power supply, 4x for servos
• Revolutionary GeoLink support (GPS, vario, logger)
• Spirit Aero support (from 1.4.0 Aero firmware)
• All-pin protection
• Redundant internal power chain for maximum safety
• Excessive tolerance for brown-outs

Features

• Super-smooth flight control
• Paddle simulation with inexpressible feeling
• Classic flybar mechanics support
• Extreme vibration immunity for all helicopter types
• Spectrum analysis for model diagnostics
• Flight log with recorded events
• Easy configuration with setup wizard
• Smartphone or tablet support via Bluetooth and WiFi
  (Modules are sold separately)
• Spektrum, Jeti, OpenTX and HoTT radio integration
• Available for Windows, OSX, Linux, Android, iOS,
  WP, SailfishOS, FreeBSD, Raspberry Pi and more
• Stabilisation for scale pilots and beginners
• Reliable, full-featured rescue system
• Integrated Bank Switching
• Governor for Electric, Nitro and Gasser Helicopters
• BEC tester with load verification
• Support for PWM, Futaba S-BUS, PPM,
  Spektrum DSM2/DSMX, JETI Duplex EX Bus,
  SRXL/Graupner SUMD/JETI UDI/JR X-Bus receivers
• Support for all servo types:
  1520/960/760us @ 50 - 560Hz
• Support for CCPM 90/120/135/140°

Package content

• Spirit 2 unit
• USB interface
• 15cm receiver cables
• 10cm 3M VHB doublesided adhesive tape
